CLV63x CLV64x CLV65x
Switching inputs Standard version: 2 (“Sensor 1”, “Sensor 2”), 2 additional inputs via
CMC600 in the CDB620
Ethernet version: 1 (“Sensor 1”), 2 additional inputs via CMC600 in the
CDB620, opto-decoupled, U
e
= max. 32 V, reverse polarity protected,
can be wired via PNP output, adjustable debouncing 0 ... 10000 ms
Switching outputs Standard version: 2 (“Result 1”, “Result 2”), 2 additional outputs via
CMC600 in the CDB620
Ethernet version: no output, 2 outputs via CMC600 in the CDB620
PNP, I
a
= max. 200 mA, short-
circuit protected,
pulse duration adjust‐
able (static,
10 ... 1000 ms)
PNP, I
a
= max. 100 mA, short-circuit protected,
pulse duration adjustable (static,
10 ... 1000 ms)
Reading pulse Pulse source for start: “Sensor 1” and/or “Sensor 2” switching inputs;
commando, auto pulse, CAN
Pulse source for stop: “Sensor 1”, “Sensor 2” reading cycle source;
commando, timer, Good Read, condition
Optical indicators 6 LED s (Ready, Result, Laser, Data, CAN, LNK TX)
Bar graph display of percentage read rate (10 LEDs)
Acoustic indicator Beeper, can be switched off, can be allocated function for event status
indication
Operating elements 2 pushbuttons
Parameter memory micro SD card (optional) or connection module with CMC600
Configuration soft‐
ware
SOPAS ET
12.4 Mechanics/electronics
CLV63x CLV64x CLV65x
Electrical connection Standard version: Cable (0.9 m) with 15-pin. D-Sub-HD male connector
Ethernet version: Swivel connector with 2 M12 round connectors (12-
pin or 17-pin male connector, 4-pin female connector)
Supply voltage 18 V DC ... 30 V DC (type-dependent), LPS without NEC Class 2
Power consumption
(for outputs without
load)
Line/Grid scanner:
Typically 5 W at DC
24 V ± 10%
Line/Grid scanner:
Typically 5.5 W at DC
24 V ± 10%
Line scanner: Typically
8.5 W at DC 18...30 V
Power consumption
(devices with heating)
Max. 40 W (max. 2,4 A)
Housing Aluminum die cast
Housing color Light blue (RAL 5012)
Electrical protection
class
III (EN 60950-1: 2011-01)
Weight Standard version: 320 g with connecting cable (reading window on
front), 340 g (reading window on side)
Ethernet version: 250 g with connecting cables (reading window on
front), 270 g (reading window on side)
Enclosure rating IP 65, according to EN 60529 (1991-10); A1 (2002-02)
TECHNICAL DATA 12
8019588/2017-01-20 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x
63
Subject to change without notice
