14.4 Dimensional drawings
Current dimensional drawings for your respective device can be found at:
•
www.sick.com/CLV63x
•
www.sick.com/CLV64x
•
www.sick.com/CLV65x
14.5 Abbreviations used
CAN Controlled Area Network. Field bus log based on the CAN bus
CDB Connection Device Basic
CDF Connection Device Fieldbus
CDM Connection Device Modular
CE Communauté Européenne. European Community
CLV Code-Leser V-Prinzip [Code reader V principle]
CMC Connection Module Cloning
CMD Connection Module Display
CMF Connection Module Fieldbus
CMP Connection Module Power
CA CodeAngle
DOF Depth Of Field. Depth of field
ESD Electro-Static Discharge. Electrostatic discharge
GSD General Station Description (generic station description for PROFIBUS/
PROFINET)
HTML Hyper Text Markup Language (page description language on the Internet)
I Input
LED Light Emitting Diode. Light emitting diode
LPS Limited Power Supply
MAC Medium Access Control
MTTF Mean Time To Failure
MTTR Mean Time To Repair
O Output
PROM Programmable Read Only Memory. Programmable non-volatile memory
RA Reading Angle
RAM Random Access Memory. Direct-access volatile memory
ROM Read Only Memory. Read-only memory (non-volatile)
RTF Rich Text Format (standardized document format with format description)
SD Secure Digital
SMART SICK Modular Advanced Recognition Technology
SOPAS-ET SICK Open Portal for Application and Systems Engeneering Tool (PC soft‐
ware for Windows for the configuration of the device)
PLC Progammable Logic Controller
TCP/IP Transmission Control Protocol/Internet Protocol
Table 14: Abbreviations used
ANNEX 14
8019588/2017-01-20 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x
77
Subject to change without notice
