SICK CLV63x - Page 66

800
(31.5)
600
(23.62)
400
(15.75)
200
(7.87)
0
Reading distance in mm (inch)
Resolution
a: 0.35 mm (13.8 mil)
c: 1.0 mm (39.4 mil)
b: 0.50 mm (19.7 mil)
–400
(–15.75)
–300
(–11.81)
–200
(–7.87)
–100
(–3.94)
100
(3.94)
200
(7.87)
300
(11.81)
400
(15.75)
0
Reading field height in mm (inch)
a
b
c
Figure 43: Reading field diagram CLV630, long range, oscillating mirror, reading window on side
12.6.2.2 Mid range
500
(19.69)
300
(11.81)
400
(15.75)
200
(7.87)
100
(3.94)
0
Reading distance in mm (inch)
Resolution
a: 0.25 mm (9.8 mil)
c: 0.50 mm (19.7 mil)
b: 0.35 mm (13.8 mil)
–100
(–3.94)
–200
(–7.87)
100
(3.94)
200
(7.87)
0
Reading field height in mm (inch)
a
b
c
For devices with plastic reading window, the depth of
field is reduced by approx. 10 %.
Figure 44: Reading field diagram CLV631, mid range, oscillating mirror, reading window on side
12 TECHNICAL DATA
66
