12.6.2.3 Short range
300
(11.81)
180
(7.09)
240
(9.45)
120
(4.72)
60
(2.36)
0
Reading distance in mm (inch)
Resolution
a: 0.20 mm (7.9 mil)
c: 0.50 mm (19.7 mil)
b: 0.35 mm (13.8 mil)
–80
(–3.15)
–40
(–1.57)
–120
(–4.72)
40
(1.57)
120
(4.72)
80
(3.15)
0
Reading field height in mm (inch)
a
b
c
Figure 47: Reading field diagram CLV632, short range, reading window on side
300
(11.81)
180
(7.09)
240
(9.45)
120
(4.72)
60
(2.36)
0
Reading distance in mm (inch)
Resolution
a: 0.20 mm (7.9 mil)
c: 0.50 mm (19.7 mil)
b: 0.35 mm (13.8 mil)
–80
(–3.15)
–40
(–1.57)
–120
(–4.72)
40
(1.57)
120
(4.72)
80
(3.15)
0
Reading field height in mm (inch)
a
b
c
For devices with plastic reading window, the depth of
field is reduced by approx. 10 %.
Figure 48: Reading field diagram CLV632, short range, reading window on front
12
TECHNICAL DATA
68
