500 700 900 1100 1300 1500 1700 1900 2100
1300
1200
1100
1000
900
800
700
600
Standard Density: line scanner CLV690-0xxxScanning frequency (Hz)
Radial reading distance (mm)
Resolution:
0.35mm
0.50mm
Figure 87: CLV690-0xxx (Standard Density): scanning frequency characteristic curve depending on the radial reading distance
and resolution
12.6.4 Standard Density: reading performance data, line scanner with oscillating mirror
600
400
400 700 13001000 1600 1900 2200
200
0
–200
–400
–600
Reading field height in mm
Resolution
a: 0.30mm
b: 0.35mm
c: 0.50mm
a
b
c
Reading distance in mm
Figure 88: CLV690-1xxx (Standard Density): reading field height depending on the reading distance and resolution
TECHNICAL DATA 12
8014396/ZMG8/2017-07-04 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV69x
105
Subject to change without notice
