12 Technical data
NOTE
The relevant online data sheet for your product can be downloaded, saved, and printed,
including technical data, dimensions, and connection diagrams:
b
www.sick.com/CLV69x
12.1 Optics
CLV690-0/1 Standard
Density
CLV691-0/1 Low Den‐
sity
CLV692-0/1 High
Density
Focus Auto focus, alternative: dynamic focus setting or fixed focus
Focus trigger source Data interface/switching inputs
No. of distance config‐
urations
≤ 8
Focus adjustment
time
≤ 20 ms
Light source Visible red light (660 nm)
MTBF 100,000 h
Laser class Class 2 according to EN/IEC 60825-1:2014
Identical laser class for issue EN/IEC 60825-1:2007
Complies with 21 CFR 1040.10 except for tolerances according to
Laser Notice no. 50 from June 24, 2007
Aperture angle Front-end: ≤ 60°
Oscillating mirror: ≤ 50°
Scanning frequency 400 Hz ... 1200 Hz
Code resolution 0.25 mm ... 1.0 mm 0.35 mm ... 1.2 mm 0.17 mm ... 0.4 mm
Reading distance 500 mm ... 2100 mm 500 mm ... 2200 mm 400 mm ... 1600 mm
(type-dependent)
Oscillating mirror
functions
Fixed (adjustable position), oscillating (variable or fixed amplitude),
one-shot
Oscillation frequency: 0.5 Hz ... 4 Hz
Angle of deflection: -20° ... 20° (can be adjusted using software)
12.2 Performance
CLV690-0/1 Standard
Density
CLV691-0/1 Low Den‐
sity
CLV692-0/1 High
Density
Bar code types 2/5 Interleaved, Codabar, Code 128, Code 39, Code 93, GS1-128/EAN
128, UPC/GT IN/EAN
Print ratio 2:1 ... 3:1
Bar code print con‐
trast (PCS)
≥ 60%
Ambient light immun‐
ity
2000 lx, on bar code
No. of codes per scan 1 ... 20 (standard decoder)
1 ... 6 (SMART decoder)
No. of codes per read‐
ing interval
1 ... 50 (auto-discriminating)
12 TECHNICAL DATA
96
