SICK CLV69x User Manual

CLV690-0/1 Standard
Density
CLV691-0/1 Low Den‐
sity
CLV692-0/1 High
Density
Supply voltage Device without heating:
18 V DC ... 30 V DC (type-dependent), LPS or NEC Class 2, SELV as per
currently valid EN 60950-1, reverse polarity protected
Device with heating:
21.6 V DC ... 28.8 V DC (type-dependent), LPS or NEC Class 2, SELV as
per currently valid EN 60950-1, reverse polarity protected
Power consumption
(with unloaded out‐
puts)
Device without heating (I
max
= 1 A):
Line scanner (LS): typ. 15 W
LS with oscillating mirror: typ. 17 W
Device with heating (I
max
= 4 A):
Line scanner (LS): typ. 78 W
LS with oscillating mirror: typ. 80 W
Housing/reading win‐
dow
Aluminum die cast/glass
(optional) plastic (CLV690-0010)
Housing color Light blue (RAL 5012)
Electrical safety as per UL 60950-1 certification
Safety EN 60950-1: 2006-04/A11: 2009-03/A1: 2010-03/A12: 2011:02
Weight Line scanner: 1500 g
Line scanner with oscillating mirror: 2200 g
Dimensions (L x W x
H)
Front-end: 117 mm x 117 mm x 94 mm
Oscillating mirror: 182 mm x 128 mm x 97 mm
Enclosure rating IP 65
12.5 Ambient data
CLV690-0/1 Standard
Density
CLV691-0/1 Low Den‐
sity
CLV692-0/1 High
Density
Interference emission EN 61000-6-4: 2007-01/A1: 2011-02
Immunity to electrical
noise
EN 61000-6-2: 2005-08
Vibration resistance EN 60068-2-6: 2008-02
Shock resistance EN 60068-2-27: 2009-05
Ambient operating
temperature
Device without heating:
0 °C ... +40 °C
Device with heating:
-35 °C ... +35 °C
Storage temperature -20 °C ... +70 °C
Permissible relative
humidity
0% ... 90%, non-condensing
12.6 Reading field diagrams
12.6.1 Reading field conditions
Test code Code 128
Print contrast >90%
Tilt ±45°
Ambient light <2000 lx
Good read rate >75%
