Table 19: Outputs
Output Description
Output Data type: Boolean
If all e
valuated inputs = 1, the output = 1.
Table 20: Parameter
Parameter Description
Number of inputs
r
equired
2 … 8
invert You can individually invert any visible input. At an inverted input, a 0
w
orks internally in the same way as a 1 and vice versa.
7.6.2.1.3 OR V1
Overview
If a
t least one of the evaluated inputs = 1, the output = 1.
Principle of operation
Table 21: Inputs
Input Description
Input 1
In
put 2
Data type: Boolean
Input 3 … Input 8
(opt
ional)
Table 22: Outputs
Output Description
Output Data type: Boolean
If at least one of the evaluated inputs = 1, the output = 1.
Table 23: Parameter
Parameter Description
Number of inputs
r
equired
2 … 8
invert You can individually invert any visible input. At an inverted input, a 0
works internally in the same way as a 1 and vice versa.
7.6.2.1.4 XOR V1 (exclusive OR)
Overview
If bo
th inputs are complementary, then the output = 1.
Principle of operation
Table 24: Inputs
Input Description
Input 1
In
put 2
Data type: Boolean
Table 25: Outputs
Output Description
Output Data type: Boolean
If bo
th inputs are complementary, then the output = 1.
7 CONFIGURATION
58
O P E R A T I N G I N S T R U C T I O N S | Flexi Compact 8024589/2020-11-10 | SICK
Subject to change without notice
