Approach
1.
In the Navigation under CPU main module, click on Device identification.
2. Specify device identification attributes for the safety controller.
7.4.3 Protecting the configuration in the SmartPlug with a password
Approach
1.
In the Navigation under CPU main module, click on Password protection.
2. Select the Upload only as authorized client option.
Complementary information
The password is stored in the SmartPlug. The password protection is therefore still
effective if the main module is replaced.
7.4.4 Adding expansion modules
Overview
T
he Catalog shows, in the Modules area, all expansion modules that can be added. A
version can be selected for the module, if applicable.
Approach
1. In the Navigation pane, click on Hardware configuration.
2. In the Catalog under Modules, select the version of an expansion module if applica‐
ble.
3. Drag an expansion module in the Catalog to the desired position. Alternatively,
double-click on an expansion module.
✓
The expansion module is added to the workspace.
7.4.5 Input elements
Table 9: Categories of input elements
Category Details in the configuration software report Examples
Mode Test pulses Other parame‐
t
ers
Electro-mechanical switch/safety
switch (EMSS)
Contract based single-channel/dual-
channel electro-mechanical switch/
safety switch without signal process‐
ing unit
•
S
ingle-channel
input
•
Dual-channel
equivalent input
•
Dual-channel
complementary
input
•
Without test
pulse (deacti‐
vated)
•
Test pulse
duration =
2 ms
•
Magnetic safety switches
•
Emergency stop pushbut‐
ton
•
Reset switch
•
Safety door limit switch
•
Two-hand control devices
•
Enabling pushbutton
•
Operating mode selector
switch
Safety sensors with monitored
semic
onductor output (OSSD)
Safety sensors with dual-channel
cross-circuit monitored semi-con‐
ductor outputs
Dual-channel equiv‐
alent input
Without test
pulse (deacti‐
vated)
OSSD test
pulse filter
active
•
T
ransponder safety switch
e.g., Sistra
•
Safety light curtain e.g.,
deTec4
•
Safety laser scanner e.g.,
microScan3, nanoScan3
Safety sensors with test input
S
afety sensors with a test input, sig‐
nal processing unit and test output
Single-channel
input
Test pulse dura‐
tion ≥ 4 ms
•
T
ype 2/4 safety photoelec‐
tric sensor e.g., L41
•
Flexi Loop
CONFIGURATION 7
8024589/2020-11-10 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Compact
45
Subject to change without notice
