SICK Flexi Compact User Manual

7.6.2.3.4 Adjustable off-delay timer V1
Overview
T
his function block outputs a falling signal edge (1–0) at the Control input at the Enable
output after a delay.
You can configure up to four delay times. The delay times are activated via the associ‐
ated inputs. The total delay time at the Enable output is equal to the sum of all the
activated delay times.
Principle of operation
T
able 57: Inputs
Input Description
Control Data type: Boolean
Delay 1 … Delay 4
(opt
ional)
Data type: Boolean
Table 58: Outputs
Output Description
Enable Data type: Boolean
If t
he Control input returns to 1 before the selected total delay time
expires, the Enable output remains = 1
Time changed Data type: Boolean
If t
he resultant delay time is changed while the Control input is being
output after a delay (i.e., the timer is still running at the moment the
time is changed), then the Time changed output = 1.
The previously set delay time continues to apply. The new delay time
only becomes active at the next delay cycle.
Table 59: Parameter
Parameter Description
Delay 1 … Delay 4 0 … 600 s in 1 ms increments
An in
put is only available if you configure a delay time
> 0 for the corresponding parameter.
CONFIGURATION 7
8024589/2020-11-10 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Compact
67
Subject to change without notice
