Presentation Scanning
Operating Instructions
IDM corded
& IDM Bluetooth
22
© SICK AG · Germany · All rights reserved · Subject to change without notice
8017159/142O/2019-05-23
to radio coverage, you will hear 4 beeps in ascending tone to indicate the radio connection is rebuilt and the
scanner will give 1 blue blink per 2.5 seconds. At the same time, all stored scanned data will be transmitted
automatically right after the radio link is resumed.
2.5 Presentation Scanning
The Presentation Scanning is designed for hand-free applications. If the “Presentation Scanning Auto-sense”
function is enabled, the scanner is capable of automatically switching to presentation mode as soon as you
place the scanner onto the Presentation Stand or into Smart Cradle.
Presentation scanning on cradle is only available for IDMx41
series.
Disable Auto-sense
Enable Auto-sense
2.6 Battery status (IDM Bluetooth only)
You can check battery status of the scanner by short pressing the Left Key or scanning “Check Battery Status”
command.
Check Battery Status
Available Firmware:
IDM141-3 / IDM161-3: 4.00.05 and above
IDM241-1 / IDM261-1: 2.00.03 and above
IDM241-3 / IDM261-3: 1.00.01 and above
The following corresponding flashes of the LED indicators present the current battery status of the scanner.
LED Indication
Battery Status
3 green and blue flashes
More than 75%
3 green flashes
More than 50%
3 orange flashes
More than 25%
3 red flashes
Less than 25%
2.7 Sleep Mode & Power Off
The scanner is preset to enter “Sleep Mode” if the scanner is not used after time-out duration. When the
scanner is under sleep mode, it is preset to enter “Power Off” automatically if it will not be waked up after
time-out duration.
