3.4 Keyboard Interface Control
3.4.1 Keyboard Layout (Language)
PROGRAM
F_DEFAULT
Family Code Selection P.C. Parameter Selection Option Code
Keyboard Layout
SS USA (QWERTY)  00
SS France (AZERTY) 01
SS Germany (QWERTZ) 02
SS United Kingdom (QWERTY) 03
SS Canadian French (QWERTY) 04
SS Spain (Spanish, QWERTY) 05
SS Sweden/Finland (QWERTY) 06
SS Portugal (QWERTY) 07
SS Norway (QWERTY) 08
SS Spain (Latin America, QWERTY) 09
SS Italy (QWERTY) 10
SS Netherlands (QWERTY) 11
SS Denmark (QWERTY) 12
SS Belgium (AZERTY) 13
SS Switzerland-Germany (QWERTZ) 14
SS Iceland (QWERTY) 15
SS Japan (DOS/V) 16
SS Czech (QWERTY) 17
Please refer to the ASCII/HEX Table listed in the Appendix to determine the HEX codes for characters,
symbols, and functions to be used as preamble or postamble.
To set preamble or postamble as function key output, you must enable the “Function Key Emulation” feature
first.
Keyboard Interface Message String:
Preamble Data Length Prefix Symbol ID Scanned Data Suffix Symbol ID Postamble Record Suffix
1-15
characters
2-4 digits 1 or 3 characters Variable
length
1 or 3 characters 1-15
characters
1 character
