SICK IDM260 Series

To Next Page

To Previous Page

Operating Instructions

Link Mode Quick Set

IDM corded

& IDM Bluetooth

8017159/2014-04-24

117

5.9 Link Mode Quick Set

The Link Mode commands are only relevant for IDM Bluetooth scanners.

PAIR Mode

PICO Mode

Uninstall

SSP Master

SSP Slave

HID Mode

HID Legacy Mode

HID Mode with Passkey

Main Page
