Technical specifications
102 © SICK AG · Germany · All rights reserved · Subject to change without notice 8013796/ZM63/2017-05-09
Operating Instructions
LMS5xx Laser Measurement Sensors
Chapter 10
General data
Laser class Laser class 1 according to
EN/IEC 608251:2014 (complies with
21 CFR 1040.10 and 1040.11 except for
deviations pursuant to Laser Notice No. 50,
June 2007)
Enclosure rating As per IEC 60529 Edition 2.2:2013-08
LMS500 IP 65
LMS511/LMS531/LMS581 IP 67
EMC test As per IEC 61000-6-2:2016-08,
IEC 61000-6-3:2006-07
Electrical safety As per IEC 61010-1:2010-06
Ambient operating temperature range
LMS500 0 °C +50 °C
LMS511/LMS531/LMS581
LMS511 Heavy Duty
–30 °C
–40 °C
+50 °C
+60 °C
Storage temperature range –40 °C +70 °C
max. 24 h
Humidity (taking into account the ambient operating
temperature range)
IEC 60068-2-61, method 1
Vibration resistance As per IEC 60068-2-6:2007-12
Frequency range 10 Hz 150 Hz
Amplitude 5 g RMS
Shock resistance As per IEC 60068-2-27:2008-02
Single shock 15 g, 11 ms
Continuous shock 10 g, 16 ms
Sender Pulsed laser diode
Wave length 895 nm 905 nm 915 nm
Divergence of the collimated beam (solid angle)
High Resolution
Standard Resolution
4.7 mrad
11.9 mrad
Light spot size at the front screen 13.6 mm
Light spot size at 18 m scanning range
High Resolution 99 mm
Standard Resolution 228 mm
Housing
Material GDALSI12 3.2582.05
Color LMS500 RAL 5012 (blue)
Color LMS511/LMS531/LMS581 RAL 7032 (grey)
Alloy Excellent weather resistance as per
EN 1706:2010-03, table B.1
Front screen
Material Polycarbonate
Surface finish Outside with scratch-resistant coating
Minimum Typical Maximum
Tab. 43: Data sheet LMS5xx (cont.)
