SICK LMS5 Series User Manual

Operating Instructions
LMS5xx
Technical specifications
8013796/ZM63/2017-05-09 © SICK AG · Germany · All rights reserved · Subject to change without notice 101
Chapter 10
10 Technical specifications
10.1 Data sheet LMS5xx laser measurement sensor
Minimum Typical Maximum
Functional data
Scan angle 190°
Scanning frequency
Lite
PRO/Heavy Duty
25 Hz
25 Hz
75 Hz
100 Hz
Remission 2% Several
1,000%
1)
(reflectors)
Angular resolution
Lite
PRO/Heavy Duty
0.25°
0.1667°
1°
1°
Measurement accuracy
2)
Standard Resolution ±24 mm
High Resolution ±12 mm
Measurement error 1st reflected pulse
3)
Systematic error (at 10% object remission
4)
)
Standard Resolution 1 to 10 m ±25 mm
Standard Resolution 10 to 20 m ±35 mm
Standard Resolution 20 to 30 m ±50 mm
High Resolution 1 to 10 m ±25 mm
High Resolution 10 to 20 m ±35 mm
Statistical error (1) (at 10% object remission
4)
)
Standard Resolution 1 to 10 m ±6 mm
Standard Resolution 10 to 20 m ±8 mm
Standard Resolution 20 to 30 m ±14 mm
High Resolution 1 to 10 m ±7 mm
High Resolution 10 to 20 m ±9 mm
Immunity to external light 70 klx
Distance from mirror axis of rotation (zero point on the
x and y axis) to the rear of the device
93 mm
Distance between centre of the scan plane and the
bottom edge of the housing
63 mm
Distance measuring range 0.7 m 80 m
Distance measuring range at 10% object remission
LMS500-2x000 Lite/PRO, LMS511-2x100 Lite/
PRO/Heavy Duty, LMS581-20100 PRO
0.7 m 26 m
LMS511-1x100 Lite/PRO/Heavy Duty, LMS531-
11100 Lite/PRO, LMS581-10100 PRO
1 m 40 m
Power-up delay 30 s 60 s
Tab. 43: Data sheet LMS5xx
