Operating Instructions
LMS5xx
Troubleshooting
8013796/ZM63/2017-05-09 © SICK AG · Germany · All rights reserved · Subject to change without notice 97
Chapter 9
9 Troubleshooting
Claims under the warranty rendered void!
The housing of the LMS5xx is sealed. Type-dependent, the devices have a diffent quanitity
of sealing stickers across their components. Claims under the warranty against SICK AG will
be rendered void if the screwed housing is opened and/or the seals are damaged.
The housing is only allowed to be opened by SICK authorized service personnel.
The only exception in this case is the process of replacing an LMS500 Lite/Pro Indoor or
LMS511 Heavy Duty Outdoor with an appropriate replacement device. Here, the system
connector is transferred from the existing device to the replacement device. See section 8.2
“Exchanging an LMS5xx” on page 91.
This chapter describes how to identify and rectify errors and malfunctions of the LMS5xx.
9.1 In the event of faults or errors
Danger due to malfunction!
Cease operation if the cause of the malfunction has not been clearly identified!
 Stop the machine/system if you cannot clearly identify or allocate the error and if you
cannot safely rectify the malfunction.
9.2 Error displays of the indicator lights
Display Possible cause Rectification of the error
Ù andØoff
No operating voltage, or
voltage too low
 Check the voltage supply and activate, if
necessary.
Ð illuminated
Front screen lightly
contaminated (warning)
 Clean the front screen.
Ð flashes with 1 Hz
Front screen heavily
contaminated (error)
 Clean the front screen.
Ð illuminated
System error  Pay attention to the error display of the
7segment display or carry out a
diagnostics with the aid of SOPAS ET.
 Switch the device off and back on again.
Tab. 41: Error displays of the LEDs
