Operating Instructions
LMS5xx
Electrical installation
8013796/ZM63/2017-05-09 © SICK AG · Germany · All rights reserved · Subject to change without notice 67
Chapter 6
6.3 Connections of the LMS5xx
Depending on the variant, the LMS5xx has different connections:
All variants:
USB:
 Mini USB connector on the front of the unit for connection to the USB interface on a PC.
The USB interface is only used for configuration and is not allowed to be permanently
connected.
 Before connecting the device to the PC install the required USB driver for using the USB
interface. The USB driver can be downloaded from the online product page:
http://www.sick.com/lms5xx
Ethernet:
 4-pole round M12 plug-in connector for the connection to Ethernet.
Indoor variants:
LMS500 Lite/PRO
The LMS500 Lite/PRO Lite Indoor has a removable system connector. This has two M16
screw type cable entries on the top. The wires of the cables have to be connected to the
both type-dependent screw type terminals in the system connector.
Outdoor variants:
LMS511 Lite/PRO
 The LMS511 Lite Outdoor has one 5-pole round M12 plug-in connector and two 8-pole
round M12 plug-in connectors.
 The LMS511 PRO Outdoor has one 5-pole round M12 plug-in connector and two 12-
pole round M12 plug-in connectors.
 The LMS511 Heavy Duty Outdoor has also a removable system connector, but only for
the purpose of replacing a device. The connector has one 5-pole round M12 plug-in
connector and two 12-pole round M12 plug-in connectors.
The connections are made to the related male connectors or female connectors of the
cables.
LMS531 Lite/PRO Security
 The LMS531 Lite Security Outdoor has one 5-pole round M12 plug-in connector and two
8-pole round M12 plug-in connectors.
 The LMS531 PRO Security Outdoor has one 5-pole round M12 plug-in connector and
two 12-pole round M12 plug-in connectors.
The connections are made to the related male connectors or female connectors of the
cables.
LMS581 PRO
 The LMS581 PRO Outdoor has one 5-pole round M12 plug-in connector and two 12-
pole round M12 plug-in connectors.
The connections are made to the related male connectors or female connectors of the
cables.
