Product description
20 © SICK AG · Germany · All rights reserved · Subject to change without notice 8013796/ZM63/2017-05-09
Operating Instructions
LMS5xx Laser Measurement Sensors
Chapter 3
3.3 Type code
3.3.1 Marking scheme of standard variants
LMS a b c - d e f gg
Not all possible combinations are available according to the type code.
Placeholder Characteristics Variant
a Device family 5: LMS5xx
b Design 0: Indoor housing without heating, IP 65
1: Outdoor housing with heating, IP 67
2: Security indoor housing without heating, IP 65
3: Security outdoor housing with heating, IP 67
7: Indoor housing without heating, IP 65, special
8: Outdoor housing with heating, IP 67, special
c Color 0: blue
1: gray
2: black
3: white
d Performance 1: Standard resolution
2: High resolution
e Variant 0: PRO
1: Lite
2: Heavy Duty
f Connectivity 0: Cable gland / 1x M12
1: M12 Standard
2: M12 CAN
gg Application 00: Standard
51: Special
90: Bulkscan software
Tab. 7: Type code of LMS5xx
