SICK LMS5 Series User Manual

Operating Instructions
LMS5xx
Product description
8013796/ZM63/2017-05-09 © SICK AG · Germany · All rights reserved · Subject to change without notice 21
Chapter 3
3.4 Special features of the LMS5xx
Variant Special features
All  Field of view maximum 190°
 Angular resolution
Lite: 0.25/0.5/1°
PRO/Heavy Duty: 0.1667/0.25/0.3333/0.5/0.6667/1°
 Scanning frequency
Lite: 25/35/50/75 Hz
PRO: 25/35/50/75/100 Hz
 Flexible system configurations
 Configuration and measured data request using SICK command language (CoLa)
 Digital switching inputs
Lite: 2 inputs
PRO/Heavy Duty: 4 inputs
 Digital switching outputs
Lite: 3 outputs
PRO/Heavy Duty: 6 outputs
 Data interfaces
Lite: Ethernet, RS232/-422, USB
PRO: Ethernet, RS232/-422, USB, CAN
PRO/Heavy Duty: Ethernet, RS232/-422, USB, CAN für Erweiterungsmodul
Measured value output (raw data)
 Non-contact, active distance measurement technique
 Measurement of objects with almost any shape
 Measured value output for all reflection pulses (echoes), e.g. in rain or on measurement through a window
Integrated field application
 Configurable evaluation fields
Lite: 4 fields
PRO: 10 fields
Heavy Duty: 10 fields
 Monitoring of the evaluation field contours
 Activation of the evaluation fields using digital switching inputs
 Encoder inputs (PRO and Heavy Duty version only)
 Output of the evaluation field (unoccupied or infringed) via digital switching outputs or telegrams
LMS500-2x000
Lite/PRO
 Scanning range up to 80 m with > 100% object remission (26 m with 10% object remission)
 Housing with enclose rating IP 65
LMS511-1x100,
LMS581-10100
 Scanning range up to 80 m with > 100% object remission (26 m with 10% object remission)
 Outdoor housing with enclose ratingIP 67
LMS511-2x100,
LMS581-20100
 Scanning range up to 80 m with > 100% object remission (40 m with 10% object remission)
 Outdoor housing with enclose rating IP 67
LMS531-11100
Lite
 Scanning range up to 80 m with > 100% object remission (40 m with 10% object remission)
 Outdoor housing with enclose rating IP 67
 2 potential-free relay outputs
 2 digital switching inputs, 1 switching output
LMS531-10100
PRO
 4 potential-free relay outputs
 4 digital switching inputs
Tab. 8: Special features of the LMS5xx variants
