Product description
38 © SICK AG · Germany · All rights reserved · Subject to change without notice 8013796/ZM63/2017-05-09
Operating Instructions
LMS5xx Laser Measurement Sensors
Chapter 3
Fig. 21: Typical RSSI values SR
The RSSI values may vary slightly between different devices and over the life time of the
sensor.
PROJECT TREE, LMS…, PARAMETER, DATA PROCESSING/OUTPUT DATA CONFIGURATION.
RSSI [digit]
Distance [m]
White (approx. 100 %)
Grey (approx. 50 %)
Black (approx. 10 %)
Reflector (> 80,000 %)
Max. signal
