Product description
40 © SICK AG · Germany · All rights reserved · Subject to change without notice 8013796/ZM63/2017-05-09
Operating Instructions
LMS5xx Laser Measurement Sensors
Chapter 3
3.10.1 Evaluation cases
An evaluation case defines which output field is evaluated in which way and on which output
it acts. With the LMS5xx PRO/Heavy Duty you can configure up to ten evaluation cases, the
LMS5xx Lite allows up to four evaluation cases. All configured evaluation cases are active
simultaneously.
For each evaluation case you configure in SOPAS ET:
 inputs that activate an evaluation case, if necessary
 the evaluation strategy
 the evaluation field
 the output on which the evaluation case acts
 the response time of the output
PROJECT TREE, LMS…, PARAMETER, EVALUATION CASES.
Inputs
If the evaluation case is not to be permanently active, then you can configure an input
combination to activate the evaluation case.
Important An input combination can also be defined for several evaluation cases, e.g. two evaluation
cases will then be active simultaneously.
Although the LMS5xx Lite has two inputs, only IN1 can be used for the field evaluation.
Input 1Input 2Input 3Input 4Evaluation case
Low Low Low Low 1
Low Low Low High 2
Low Low High Low 3
Low Low High High 4
Low High Low Low 5
Low High Low High 6
Low High High Low 7
Low High High High 8
High Low Low Low 9
High Low Low High 10
Tab. 15: Input combination examples LMS5xx PRO
1)
1) In SOPAS ET, the output state High is referred to as “Active high”. Similarly, the output state Low is referred to
as “Active low”.
