a: 10 klx
b: 40 klx
c: 80 klx
0
10
20
30
50
60
40
Object remission in %
Measuring range in m (ft)
0 20
(65.6)
70
90
100
80
abc
10
(32.8)
30
(98.4)
50
(164.0)
40
(131.2)
60
(196.9)
Figure 9: Scanning range as a function of object remission for various ambient light influences
(no filter activated; no influence from fog, rain or dust)
a: 10 klx
b: 40 klx
c: 80 klx
Statistical error in mm (in)
0
0 40
(131.2)
50
(164.1)
60
(196.9)
5
(0.20)
10
(0.39)
15
(0.59)
20
(0.79)
Object distance in m (ft)
20
(65.6)
10
(32.8)
30
(98.4)
c
b
a
Figure 10: Statistical error for white objects as a function of object distance for various ambient
light influences
PRODUCT DESCRIPTION
3
8020494/1AZF/2021-05-10 | SICK O P E R A T I N G I N S T R U C T I O N S | MRS1000
15
