SICK MRS1000 User Manual

10 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/MRS1000
Please note: This documentation may contain further technical data.
10.1
Features
Measurement principle HDDM+
Application MRSxxxxx-0xxxxx: Indoor
MRSxxxxx-1xxxxx: Outdoor
Light source Infrared (wavelength 850 nm, max. output power 1.26 W, pulse
duration 3.5 ns, average power 4.0 mW)
Laser class Laser class 1 (EN/IEC 60825-1:2014, EN/IEC 60825-1:2007)
Complies with 21 CFR 1040.10 and 1040.11 except for devia‐
tions pursuant to Laser Notice No. 50, dated June 24, 2007.
Horizontal aperture angle 275°
Vertical aperture angle 7.5° (over 4 measurement levels)
Scan field flatness Conical error: ± 0.6°
Tilt: ± 0.6°
Scanning frequency 50 Hz, 4x 12.5 Hz
Angular resolution 0.25°, 0.125° (interlaced mode), 0.0625° (interlaced mode)
Heating self-heating
Working range 0.2 m ... 64 m
Scanning range with 10%
remission
16 m
Scanning range with 90%
remission
30 m
Spot divergence 10.4 mrad x 8.7 mrad
Light spot size at front
screen
7 mm rounded
Number of echoes evalu‐
ated
3
TECHNICAL DATA 10
8020494/1AZF/2021-05-10 | SICK O P E R A T I N G I N S T R U C T I O N S | MRS1000
51
Subject to change without notice
