ã
Detection area
e
Measuring range
10.4 Performance
Scan/frame rate 55000 … 165000 measuring points/second
Response time typically 20 ms (4 layers), typically 80 ms (1 layer)
min. 7 ms, max. 84 ms + 1 scan
Systematic error ± 60 mm
Temperature drift: Typically ± 0.5 mm/K
Statistical error ≤ 30 mm
Integrated application Integrated field evaluation with flexible fields on 4 levels, data
output
Number of field sets Up to 64 fields
Simultaneous analysis
cases
Up to 16 analyses
Filters Fog filter, particle filter, average filter, median filter, ground refer‐
ence evaluation, edge filter, echo filter
1)
Depends on the object size and selected filter settings.
10.5 Interfaces
Ethernet , TCP/ IP, UDP/ IP
Function: HOST, OPC, NTP
Measured data output (distance, RSSI)
Data transmission rate: 10/100 Mbit/s
digital inputs/outputs I/O (8 (multiport))
Output data Contamination indication, IMU (secondary sensor data)
Optical indicators 2 LEDs
Configuration software SOPAS ET, web server (display)
10.6 Ambient data
Object remission 2% ... > 1,000% (reflector)
Electromagnetic compati‐
bility (EMC)
EN 61000-6-2:2005
EN 61000-6-3:2007+A1:2011
Vibration resistance EN 60068-2-6:2007
Shock resistance EN 60068-2-27:2008
Ambient operating temper‐
ature
MRSxxxx-0xxxxx: -10 °C … +50 °C
MRSxxxx-1xxxxx: -30 °C … +50 °C
Storage temperature -40 °C … +75 °C
Operating and storage air
humidity
Max 90% air humidity (non-condensing)
Ambient light immunity 80 klx
TECHNICAL DATA 10
8020494/1AZF/2021-05-10 | SICK O P E R A T I N G I N S T R U C T I O N S | MRS1000
55
Subject to change without notice
