SICK MRS1000

Working range diagram
Scanning range in m
Scanning range in m
–20–40 20 40 60
–60
0
Scanning range max. 64 m
Scanning range for objects up to 10 % Remission 16 m
–40
40
–80
60
–20
20
0
Scanning range for objects up to 90 % remission 30 m
80
–60
275°
80
–80
Figure 42: Working area diagram, top view
