3RP25 Time Relays
Manual, 09/2019, A5E31947765002A/RS-AC/003
31
5.1 Terminal assignment
Location of the connections
The inside faces of the terminal covers are labeled with the designations of the relevant
terminals. The position of the label corresponds to the position of the respective terminal.
When using the terminal blocks, you must observe the correct position of the blocks (see
inside of cover).
Figure 5-1 Upper terminal cover
