Connection
5.5 Disconnecting the screw-type terminals
3RP25 Time Relays
40 Manual, 09/2019, A5E31947765002A/RS-AC/003
5.5 Disconnecting the screw-type terminals
Hazardous Voltage
Can Cause Death, Serious Injury, or Property Damage.
Before starting work, therefore, disconnect the system and devices from the power supply.
Requirements
● Cross-tip screwdriver size PZ 1 x 80
Procedure
Unscrew the screw of the screw-type terminal.
2 Remove the cable from the unscrewed
screw-type terminal.
