Engineering and remote access
3.5 Cyclic and acyclic data
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
105
Data
Description
Data type
Stop buffering voltage Stop buffering voltage Unsigned16
from V2.2
Battery type Battery type Unsigned8 from
V2.2
Order number Order number VisibleString(19)
from V2.2
Serial number Serial number VisibleString(15)
from V2.2
Manufacturing date Manufacturing date 3 × Unsigned8
from V2.2
Version number Version number 2 × Unsigned8
from V2.2
0x0020: State information (reading)
Data
Description
Data type
Remaining buffer time [1 s] Probable remaining buffer time. The remaining buffer time is cal-
culated based on the present battery charge and the average
current over a 10 minute period.
Unsigned32
Total operating time [1 h]
Total operating time.
Unsigned32
Total calculated battery capacity
[0.1 Ah]
Total calculated battery capacity Unsigned16
Calculated battery 1 capacity
[0.1 Ah]
Battery 1: Calculated battery capacity Unsigned16
Calculated battery 2 capacity
[0.1 Ah]
Battery 2: Calculated battery capacity Unsigned16
Calculated battery 3 capacity
[0.1 Ah]
Battery 3: Calculated battery capacity Unsigned16
Calculated battery 4 capacity
[0.1 Ah]
Battery 4: Calculated battery capacity Unsigned16
Calculated battery 5 capacity
[0.1 Ah]
Battery 5: Calculated battery capacity Unsigned16
Calculated battery 6 capacity
[0.1 Ah]
Battery 6: Calculated battery capacity Unsigned16
Input voltage [0.01 V] Input voltage: Measured rms value of the supply voltage at the
input of the SITOP UPS1600.
Unsigned16
Input current [5 mA]
Current measured at the input of the SITOP UPS1600.
Unsigned16
Output voltage [0.01 V]
Voltage measured at the output of the SITOP UPS1600.
Unsigned16
Load current [5 mA]
Load current measured at the output of the SITOP UPS1600.
Unsigned16
Measured charge current [1 mA]
Measured battery charge current of the SITOP UPS1600.
Unsigned16
Battery voltage [0.01 V]
Measured battery voltage of the connected battery modules
Unsigned16
Output current [5 mA]
Load current measured at the output of the SITOP UPS1600.
Unsigned16
Charge voltage [0.01 V] Voltage used to charge the batteries during the constant charging
process.
Unsigned16
Fill byte(s)
-
3 x Unsigned8
