2.4 Operating displays and signaling
SITOP UPS1600 / UPS1100
32 Manual, 04.2017, A5E37775406-8-76
LED 1 (O.K./BAT)
Signaling
6EP4134-3AB00- ...
6EP4136-3AB00- ...
6EP4137-3AB00- ...
Off
DC-UPS off
Red
DC-UPS defect (severe hardware fault)
Flashing red (0.5/0.5)
Firmware update
Flashing red (1/1)
Software corrupted
Flashing yellow
(0.5/0.5)
Critical temperature identified, overtemperature or overvoltage at the input
Flashing yellow (0.5/3)
Buffer mode, output off
Yellow
Buffer mode, output on
Flashing green (0.5/3)
DC-UPS OK, output off
Green
DC-UPS OK, output on
LED 2 (BAT>85 %)
Signaling
6EP4134-3AB00- ...
6EP4136-3AB00- ...
6EP4137-3AB00- ...
Flashing green
(0.5/0.5)
Firmware update
Off
Battery charge state <85 %
Green
Battery charge state >85 %
The LED and the relay contact (see Chapter Relay outputs (Page 34)) have two meanings:
1. If no other settings have been made, then the LED lights up after reaching a charge state
greater than 85 %. The LED goes dark if the charge state falls below 85 %.
2. If an expected buffer current and a buffer time are set under the hardware configuration,
then the LEDs and the relay contact serve as an indicator when buffering is possible with
the two parameters – or is no longer possible.
Note
From the instant in time when the SITOP
UPS1600 is switched over into the buffer mode, for
the evaluation, instead of the expected buffer cur
rent, the actually measured buffer current is
used. As a consequence, the status of the LEDs and the relay can also change.
