2.4 Operating displays and signaling
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
33
LED 3 (alarm)
Signaling
6EP4134-3AB00- ...
6EP4136-3AB00- ...
6EP4137-3AB00- ...
Red
Output off for 45 seconds because of overcurrent, overtemperature or buffer operation not
possible
Off
Buffer operation possible
LED 4 (battery/BAT.Fault)
Signaling
6EP4134-3AB00- ...
6EP4136-3AB00- ...
6EP4137-3AB00- ...
Off
Battery O.K. or uncoded battery modules connected or buffer time rotary coding switch at
position MAX
Flashing yellow
(0.5/0.5)
Battery outside the permitted temperature range
Red
Battery defective
Yellow
Selected buffer time cannot be attained
LED 5 and LED 6 (PROFINET LEDs)
Signaling
6EP4134-3AB00-2AY0
6EP4136-3AB00-2AY0
6EP4137-3AB00-2AY0
LED 5 (SF)
LED 6 (RUN)
Off
Off
No connection to a PROFINET IO controller
Off
Flashing green
(0.5/0.5)
Configuration by the PROFINET IO controller
Off
Green
Application started successfully, module O.K.
Red
Green
Application started successfully, module not O.K.
Flashing red (0,1/0,1)
Green
Application in progress, diagnosis can be called
Flashing red (0.5/0.5)
Flashing green
(0.5/0.5)
Self-test running (flashing alternately every 3 s)
Flashing red (0.5/0.5) Off
DCP requires device identification (LED flashes for
3 seconds)
Flashing red (0.5/0.5)
Flashing green
(0.5/0.5)
Firmware update
LEDs 5 and 6 are active only for ... -2AY0.
