Engineering and remote access
3.5 Cyclic and acyclic data
SITOP UPS1600 / UPS1100
Manual, 04.2017, A5E37775406-8-76
97
Data
Description
Data type
Batt 4: Order number
Order number (Article number).
VisibleString(30)
Batt 4: Serial number Serial number VisibleString(30)
Batt 4: Manufacturing date
Manufacturing date
VisibleString(30)
Batt 4: Version number Version number VisibleString(50)
Batt 5: Standby time [1 s]
Standby time
Unsigned32
Batt 5: Buffer time [1 s] Required buffer time, after which the SITOP UPS1600 shuts down
in the buffer mode.
Unsigned32
Batt 5: Total charging current
[1 mAh]
Total charge level (battery-specific data): Total charge within the
service lifetime of the SITOP UPS1600.
Unsigned32
Batt 5: Total culled current [1 mAh] Total charge level used (battery-specific data): Total discharge
within the service life of the SITOP UPS1600.
Unsigned32
Batt 5: EOCV [0.01 V] "End-of-charge voltage": Battery voltage when charging changes
to trickle charging. The energy storage device is then charged up
to 100 %.
Unsigned16
Batt 5: Charge current [1 mA] Charge current: Current magnitude used to charge the connected
battery modules during the constant charging process.
Unsigned16
Batt 5: Battery capacity [0.1 Ah] Battery capacity: Total battery capacity of all energy storage de-
vices connected to the
SITOP UPS1600.
Unsigned16
Batt 5: Stop buffering voltage
[0.01 V]
Stop buffering voltage: Buffer operation is exited if the battery
voltage is below this value.
Unsigned16
Batt 5: Battery type
Battery type
Unsigned8
Batt 5: Minimal temperature [1 °C] Lowest specified operating temperature of the battery module
being used SITOP UPS1100.
Signed8
Batt 5: Maximal temperature [1 °C] Highest specified operating temperature of the battery module
being used SITOP UPS1100.
Signed8
Fill byte(s)
-
3 x Unsigned8
Batt 5: Order number
Order number (Article number).
VisibleString(30)
Batt 5: Serial number
Serial number
VisibleString(30)
Batt 5: Manufacturing date
Manufacturing date
VisibleString(30)
Batt 5: Version number
Version number
VisibleString(50)
Batt 6: Standby time [1 s]
Standby time
Unsigned32
Batt 6 Buffer time [1 s] Required buffer time, after which the SITOP UPS1600 shuts down
in the buffer mode.
Unsigned32
Batt 6: Total charging current
[1 mAh]
Total charge level (battery-specific data): Total charge within the
service lifetime of the SITOP UPS1600.
Unsigned32
Batt 6: Total culled current [1 mAh] Total charge level used (battery-specific data): Total discharge
within the service life of the SITOP UPS1600.
Unsigned32
Batt 6: EOCV [0.01 V] "End-of-charge voltage": Battery voltage when charging changes
to trickle charging. The energy storage device is then charged up
to 100 %.
Unsigned16
Batt 6: Charge current [1 mA] Charge current: Current magnitude used to charge the connected
battery modules during the constant charging process.
Unsigned16
Batt 6: Battery capacity [0.1 Ah] Battery capacity: Total battery capacity of all energy storage de-
vices connected to the
'SITOP UPS1600.
Unsigned16
