Functions
8.2 Time stamping the input signals with IM 153-2
ET 200M
140 Operating Instructions, 04/2022, EWA-4NEB7806006-09
Example structure for time stamping signal changes with IM 153-2
Figure 8-9 Example structure for time stamping signal changes with IM 153-2
WinCC Operator station (OS) for unit visualization
SM 321 digital input module (6ES7321-7BH…)
Optional: RS 485 repeater
