Parameters for time stamping
Configure the time stamping with STEP 7 for the ET 200M in the DP slave properties and then
in addition for the respective digital input modules in the module properties.
Table 10- 3 Parameters for time stamping
Parameters
Range of values
Default
Scope
Time stamping
yes/no
No
ET 200M
Module
Channel
RLO edge detection
rising edge /
falling edge
Rising edge
ET 200M
Module
Channel
Time interval for
time synchronization
1 s to 60 s
(value must correspond with
the setting in the time mas-
ter)
10 s
ET 200M
Parameters for clock synchronism
Configure the isochrone mode with STEP 7 for the ET 200M in the DP slave properties and
then in addition for the respective digital input modules in the module properties.
Table 10- 4 Parameters for clock synchronism
Parameters
Range of values
Default
Scope
Synchronize the slave to the DP
cycle
block / enable
Disable
ET 200M
Time Ti
(read process values)
(Values will be specified by
STEP 7)
(Value will be specified by
STEP 7)
ET 200M
Time To
(output process values)
(Values will be specified by
STEP 7)
(Value will be specified by
STEP 7)
ET 200M
