Connecting
6.7 Fuses
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
153
Table 6- 16 Arm fuses
Device
Siemens ЯU arm fuses
Article number
I/U [A/V]
Qty
Article number
I/U [A/V]
6RA8091-6DV62-0AA0
1200 / 400
6
3NE3338-8
800 / 800
6RA8090-6GV62-0AA0
1100 / 575
6
3NE3338-8
800 / 800
6RA8090-6KV62-0AA0 1000 / 690 6 3NE3337-8 710 / 900
6RA8088-6LV62-0AA0
950 / 830
6
3NE3337-8
710 / 900
6RA8093-4DV62-0AA0
1600 / 400
6
6RY1702-0BA02
1000 / 660
6RA8093-4GV62-0AA0
1600 / 575
6
6RY1702-0BA02
1000 / 660
6RA8093-4KV62-0AA0
1500 / 690
6
6RY1702-0BA03
1000 / 1000
6RA8093-4LV62-0AA0
1500 / 830
6
6RY1702-0BA03
1000 / 1000
6RA8095-4DV62-0AA0
2000 / 400
6
6RY1702-0BA01
1250 / 660
6RA8095-4GV62-0AA0
2000 / 575
6
6RY1702-0BA01
1250 / 660
6RA8095-4KV62-0AA0
2000 / 690
12
6RY1702-0BA04
630 / 1000
6RA8095-4LV62-0AA0
1900 / 830
12
6RY1702-0BA04
630 / 1000
6RA8096-4GV62-0AA0
2200 / 575
6
6RY1702-0BA05
1500 / 660
6RA8096-4MV62-0AA0
2200 / 950
12
3NC3438-6
800 / 1100
6RA8097-4KV62-0AA0
2600 / 690
12
3NC3341-6
1000 / 1000
6RA8097-4GV62-0AA0
2800 / 575
12
3NC3341-6
1000 / 1000
6RA8098-4DV62-0AA0
3000 / 400
12
3NC3341-6
1000 / 1000
The arm fuses are included in the device. No external semiconductor fuses are required.
It is not permissible to use different fuse types together.
4Q devices: 480 V
Table 6- 17 Phase fuses
Device
3 x phase fuses
Siemens ЯU
3x phase fuses
Siemens ЯU for DCM
packages
3 x phase fuses
Bussmann ЯU
3 x phase fuses
Bussmann ЯU
Article
number
I/U
[A/V]
Article
number
I/U
[A/V]
Article
number
I/U [A/V]
Order No.
I/U [A/V]
Order No.
I/U [A/V]
6RA8013-
6FV62-0AA0
15 / 480 3NE1814-0 20 /
690
3NE1814-0 20 / 690 170M1562 32 / 660 FWH-35B 35 / 500
6RA8018-
6FV62-0AA0
30 / 480 3NE1815-0 25 /
690
3NE1815-0 25 / 690 170M1562 32 / 660 FWH-35B 35 / 500
6RA8025-
6FV62-0AA0
60 / 480 3NE1817-0 50 /
690
3NE1817-0 50 / 690 170M1565 63 / 660 FWH-60B 60 / 500
6RA8028-
6FV62-0AA0
90 / 480 3NE1820-0 80 /
690
3NE1820-0 80 / 690 170M1567 100 /
660
FWH-100B 100 /
500
6RA8031-
6FV62-0AA0
125 /
480
3NE1021-0 100 /
690
3NE1021-0 100 /
690
170M1568 125 /
660
FWH-125B 125 /
500
6RA8075-
6FV62-0AA0
210 /
480
3NE3227 250 /
1000
3NE3227 250 /
1000
170M3166 250 /
660
FWH-225A 225 /
500
