Siemens 6RA8085-6DS22

Commissioning
8.4 Commissioning using the AOP30 operator panel
SINAMICS DCM DC Converter
284 Operating Instructions, 12/2018, A5E34763375A
p50100[D]
Rated armature current
p50101[D]
Rated armature voltage
p50102[D]
Rated excitation current
p50103[D]
Minimum excitation current (optional)
p50114[D]
Thermal time constant for motor
See the section titled
"Thermal overload protection for the DC motor
(I
2
t monitoring of the motor)"
p2003
Enter the rated torque
•
If specified: refer to the manufacturer's specifications of the motor
•
Or calculate from rating plate specifications for power and rated speed:
p2003 = 9550 x rated power [in kW] / rated speed [in rpm]
Note
For 2Q devices, the rated DC voltage of the SINAMICS DCM specified in the technical data,
can only be achieved if the
α
G
limit (p50150[D]) is set to 5°. The factory setting is 30°. In
order to reach the rated motor voltage (p50101[D]), the
α
G
limit must also be changed to 5°.
When you have finished entering the motor data, choose "Continue" underneath the final
parameter value and activate with <F5> (OK).
Encoder selection
p50083[D]
Actual speed controller value selection
Analog tachometer screen
p50741[D]
Tachometer voltage at maximum speed
p2000
Reference speed
Pulse encoder screen
p0400[E]
Encoder type selection
p0404[E]
Encoder configuration active
p0405[E]
Square-wave encoder A/B
p0408[E]
Rotary encoder pulse no.
p2000
Reference speed
