7.4 Terminal Module TM15
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
235
7.4.10
Technical data
Table 7- 29 Technical data
6SL3055-0AA00-3FAx
Unit
Value
Electronic power supply
Voltage
Current (without DRIVE-CLiQ or digital outputs)
Power loss
V
DC
A
DC
W
24 (20.4 – 28.8)
0.15
< 3
Max. cable length
m
30
Peripherals
Digital inputs/outputs
Can be parameterized as either DI or DO
Number of digital inputs/outputs
24
Electrical isolation
Yes, in groups of 8
Digital inputs
Voltage
V
DC
-30 to +30
Low level (an open digital input is interpreted as
"low")
V
DC
-30 to +5
High level
V
DC
15 to 30
Input impedance
kΩ
2.8
Input current, typical (at 24 V DC)
mA
9
Max. voltage in OFF state
V
DC
5
Current in OFF state
mA
0.0 to 1.0 (per channel)
Typical input delay of the digital inputs μs "0" → "1": 50
"1" → "0": 100
Digital outputs (continuously short-circuit proof)
Voltage V
DC
24
Max. load current per digital output
A
DC
0.5
Output delay (resistive load)
Typical μs "0" → "1": 50
"1" → "0": 150
Maximum μs "0" → "1": 100
"1" → "0": 225
Min. output pulse
(100% amplitude, 0.5 A with resistive load)
μs 125 (typ.)
350 (max.)
Switching frequency
For resistive load
For inductive load
For lamp load
Max. lamp load
Hz
Hz
Hz
W
max. 100
max. 0.5
max. 10
5
Max. switching frequency
(100% amplitude, 50%/50% duty cycle;
with 0.5 A and a resistive load)
kHz 1 (typ.)
Voltage drop in ON state V
DC
0.75 (max.) for maximum load in all
circuits
Leakage current in OFF state
μA
Max. 10 per channel
