Commissioning
8.5 Commissioning with the STARTER commissioning tool
SINAMICS DCM DC Converter
296 Operating Instructions, 12/2018, A5E34763375A
⇒ Select the following data from the list fields:
Unit:
SINAMICS
Type:
DCM Standard CUD for one standard CUD in the left
-hand slot
DCM Advanced CUD for one Advanced CUD in the left
-hand slot
DCM Standard CUD [2] for a Standard CUD in the right
-hand slot
DCM Advanced CUD [2] for an Advanced CUD in the right-hand slot
Version:
Actual version
Target device
address:
T
he corresponding bus address of the drive (126 is preset in the drive
device)
Name:
Any desired name can be entered in the name box
Note
For a download, the bus address assigned here is transferred to the device, but is not
transferred to parameter p0918.
To keep p0918 consistent with the project, after a
"Load to target device" a "Load to PG"
must still be performed
– and must be repeated after every change to p0918 using BOP20 or
AOP30.
Note
A second CUD for expanding the computing capacity is created in the STARTER as an
independent device, type
"DCM Standard (Advanced) CUD [2]".
Explanation:
"[2]" is the SINAMICS nomenclature for indexed data. In this case, it is used as
a name
– independent of any language for a second CUD inserted in the right-hand slot.
⇒
Click
Insert
The selected drive unit is displayed in the project wizard preview window.
