Operation
9.1 Basic information
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
355
Example of data set assignment
Table 9- 2 Example, data set assignment
DDS
Encoder 1 (p0187)
Encoder 2 (p0188)
DDS 0
EDS 0
EDS 1
DDS 1 EDS 0 EDS 0
DDS 2
EDS 0
EDS 0
DDS 3
EDS 1
-
9.1.2.1
Function diagrams and parameters
Function diagrams (see the SINAMICS DCM List Manual)
● 8560 Command data sets (CDS)
● 8565 Drive data sets (DDS)
● 8570 Encoder data sets (EDS)
Overview of important parameters (refer to the SINAMICS DCM List Manual)
Adjustable parameters
● p0140 Encoder data sets (EDS) number
● p0170 Command data sets (CDS) number
● p0180 Drive data sets (DDS) number
● p0187 Encoder 1 encoder data set number
● p0188 Encoder 2 encoder data set number
● p0809 Copy command data set (CDS)
● p0810 BI: Command data set CDS bit 0
● p0819[0...2] Copy drive data set DDS
● p0820 BI: Drive data set selection DDS, bit 0
● p0821 BI: Drive data set selection DDS, bit 1
