9.3 Controlling via the AOP30 operator panel
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
389
9.3.5.4
Lists of signals for the operation screen
The following tables list some of the main signals for the operation screen along with their
associated reference variables and default settings for quick commissioning.
DC_CTRL object
Table 9- 9 List of signals for the operation screen - DC_CTRL object
Signal
Parameter
Short name
Unit
Scaling (100%=...)
see table below
Factory setting (entry no.)
N setpoint following limitations
(1)
r50029
NSET
rpm
p2000
Status display
(2)
r50000
STAT
-
-
Actual EMF value (3) r52287 EMF % -
Field current actual value
(4)
r52265
I_F
%
-
Speed actual value
(5)
r00021
N_ACT
rpm
p2000
Actual armature current value
(6)
r00027
I_ACT
A
p2002
Armature firing angle
(7)
r50018
ALF_A
°
-
Field firing angle
(8)
r50034
ALF_F
°
-
Motor temperature rise
(9)
r50014.0
TEMP
%
-
Thyristor temperature rise
(10)
r50014.1
TEMP1
%
-
For diagnostic purposes
Speed setpoint smoothed
r0020
NSET
rpm
p2000
Actual speed value, motor encoder
r0061
N_ACT
rpm
p2000
Actual speed value following smoothing
r0063
N_ACT
rpm
p2000
For further diagnostic purposes
PROFIBUS setpoint
r2050
PBSET
rpm
p2000
Scalings for DC_CTRL object
Table 9- 10 Scalings for DC_CTRL object
Variable
Scaling parameter
Default for quick commissioning
Reference speed
100% = p2000
p2000
Reference voltage
100% = p2001
p2001 = 1,000 V
Reference current
100% = p2002
p2002 = Current limit (p0640)
Reference torque
100% = p2003
p2003 = 2 × rated motor torque
Reference power
100% = r2004
r2004 = (p2003 × p2000 × π) / 30
Reference temperature 100% = 100 °C -
