Siemens 6RA8085-6DS22

Descriptions of functions
10.3 Communication according to PROFIdrive
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
411
DC_CTRL
CU_DC
TM31,
TM15DI_DO,
TM150
ENCODER
Receive process data
DWORD
connector output
r2060[0 ... 62] - - r2060[0 ... 2]
WORD connector
output
r2050[0 ... 63] r2050[0 ... 19] r2050[0 ... 4] r2050[0 ... 3]
Binector output r2090.0 ... 15
r2091.0 ... 15
r2092.0 ... 15
r2093.0 ... 15
r2090.0 ... 15
r2091.0 ... 15
r2090.0 ... 15
r2091.0 ... 15
r2092.0 ... 15
r2093.0 ... 15
Free binector-
connector
converter
p2080[0 ... 15], p2081[0 ... 15], p2082[0 ... 15], p2083[0 ... 15],
p2084[0...15] / r2089[0 ... 4]
Send process data
DWORD
connector input
p2061[0 ... 62] - - p2061[0 ... 10]
WORD connector
input
p2051[0 ... 63] p2051[0 ... 24] p2051[0 ... 4] p2051[0 ... 11]
Free connector-
binector converter
p2099[0 ... 1] / r2094.0 ... 15, r2095.0 ... 15
Notes on telegram interconnections
● When you change p0922 = 999 (factory setting) to p0922 ≠ 999, the telegrams are
interconnected and blocked automatically.
● Exceptions to this are the telegrams 20, 220, and 352. Here, selected PZDs can be
interconnected as required in the send/receive telegram.
● When you change p0922 ≠ 999 to p0922 = 999, the previous telegram interconnection is
retained and can be changed.
● If p0922 = 999, a telegram can be selected in p2079. A telegram interconnection is
automatically made and blocked. The telegram can also be extended.
This is an easy method for creating extended telegram interconnections on the basis of
existing telegrams.
