Descriptions of functions
10.5 Communication via PROFINET IO
SINAMICS DCM DC Converter
488 Operating Instructions, 12/2018, A5E34763375A
4. In the selection list on the left-hand side, select the module that you want to use as the
interface.
5. Click the "Install" button.
The selected module is then listed in the "Installed" list.
6. Click the "Close" button.
You can then check the IP address of the integrated Ethernet interface as follows:
1. Select the drive unit and call the shortcut menu "Target device > Online access ...".
2. Click the "Module addresses" tab.
The IP address that you set must be located under "Connect to target station".
Figure 10-36 Setting online access
