Descriptions of functions
10.5 Communication via PROFINET IO
SINAMICS DCM DC Converter
498 Operating Instructions, 12/2018, A5E34763375A
Connecting the PC to the STARTER commissioning tool
You can go online with STARTER in a number of ways, which are illustrated below:
Figure 10-39 Connecting the IO supervisor
Note
SINAMICS does not support routing from PROFIBUS to PROFINET and vice versa.
Note
If a CBE20 Communication Board Ethernet fails (e.g. due to a power failure), then
communication with the subsequent nodes is interrupted at this point.
