Technical data
4.5 Unit data
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
59
3-ph. 400 V AC, 4Q devices
6RA8013-6DV62-0AA0
6RA8031-6DV62-0AA0
6RA8081-6DV62-0AA0
6RA8091-6DV62-0AA0
6RA8018-6DV62-0AA0
6RA8075-6DV62-0AA0
6RA8085-6DV62-0AA0
6RA8025-6DV62-0AA0
6RA8078-6DV62-0AA0
6RA8087-6DV62-0AA0
6RA8028-6DV62-0AA0
Table 4- 24 Technical data for 3-ph. 400 V AC, 4Q devices
Rated armature supply voltage
1)
V 3 AC 400 (+15% / -20%)
for devices 6RA8098-4DV62-0AA0: +10% / -20%
Electronic power supply,
rated supply voltage
V 2 AC 380 (-25%) to 480 V AC (+10%); In = 1 A or
1 AC 190 (-25%) to 240 V AC (+10%); In = 2 A
With option L05: 18 to 30 DC; In = 5 A
1)
10)
6)
Max. 1.8x rated DC current
Closed-loop control constancy Δn = 0.006% of the rated motor speed during operation with
incremental encoder
digital setpoint
Δn = 0.1% of the rated motor speed during operation with
analog tachometer or analog setpoint
5)
IP00 according to EN 60529
Protection class Class I (with protective conductor system) and class III (PELV)
according to EN 61800-5-1
Table 4- 25 Technical data for 3-ph. 400 V AC, 15 A to 90 A, 4Q devices
Rated armature input current
2)
A 12.5 24.9 49.8 74.7
Rated power kW 6.3 12.6 25.2 37.8
Power loss at rated DC current
W 131 180 250 321
Rated field supply voltage
1)
2-ph. 400 V AC (+15% / -20%)
Rated field DC voltage
1)
V 325 325 325 325
Rated DC voltage for single-phase
V 280 280 280 280
Rated DC current for
A 10.5 21.0 42.0 63.0
