Siemens 6RA8085-6DS22

Technical data
4.5 Unit data
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
67
Table 4- 35 Technical data for 3-ph. 575 V AC, 60 A to 210 A, 4Q devices
Article number 6RA80 ..
..25-6GV62-...
..31-6GV62-...
..75-6GV62-...
Rated DC current
A
60
125
210
Rated armature input current
2)
A
49.8
104
174
Rated power
kW
35
75
126
Power loss at rated DC current (approx.)
W
274
463
742
Rated field DC current
A
10
10
15
Type of cooling
Self-ventilated
Self-ventilated
Forced ventilation
Rated fan supply voltage
V
-
-
Fan with internal
power supply
Fan air flow
m
3
/h
-
-
300
Fan noise level
dB(A)
-
-
70.3
Dimensions (WxHxD)
mm
268x385x252
268x385x252
268x385x252
Weight (approx.)
kg
11
14
15
Rated DC voltage for single-phase
operation
V
400
400
-
Rated DC current for
single-phase operation
A
42.0
87.5
-
Table 4- 36 Technical data for 3-ph. 575 V AC, 400 A to 1100 A, 4Q devices
Article number 6RA80 ..
..81-6GV62-...
..85-6GV62-...
..87-6GV62-...
..90-6GV62-...
Rated DC current
A
400
600
850
1100
Rated armature input current
2)
A
332
498
706
913
Rated power
kW
240
360
510
660
Power loss at rated DC current (approx.)
W
1598
2002
2826
4022
Rated field DC current
A
25
25
30
40
Type of cooling
Forced
ventilation
Forced
ventilation
Forced
ventilation
Forced
ventilation
Rated fan supply voltage
50 Hz
V
3-ph. 400 V AC
(±15%)
clockwise phase
sequence
3-ph. 400 V AC
(±15%)
clockwise phase
sequence
3-ph. 400 V AC
(±15%)
clockwise phase
sequence
3-ph. 400 V AC
(±10%)
clockwise phase
sequence
60 Hz
V
3-ph. 460 V AC
(±10%)
clockwise phase
sequence
3-ph. 460 V AC
(±10%)
clockwise phase
sequence
3-ph. 460 V AC
(±10%)
clockwise phase
sequence
3-ph. 460 V AC
(±10%)
clockwise phase
sequence
V
With option L21: 1-ph. 230 V AC (±10%)
Rated fan current
50 Hz
60 Hz
A
0.27
8)
0.33
0.27
8)
0.33
0.27
8)
0.33
0.38
9)
0.5
Rated fan current
with option L21
50 Hz
60 Hz
A
0.68
0.95
0.68
0.95
0.68
0.95
1.16
1.7
Fan air flow
m
3
/h
600
600
600
1000
Fan noise level
50 Hz
60 Hz
dB(A)
70.3
74.4
70.3
74.4
70.3
74.4
70.4
74.2
Dimensions (WxHxD)
mm
268x625x275
268x625x275
268x700x311
268x785x435
Weight (approx.)
kg
26
31
42
78
