13.9 Circuit breakers and power contactors
SINAMICS DCM DC Converter
724 Operating Instructions, 12/2018, A5E34763375A
6RA8075_XXXXX_0AA0
Value
Designation
Manufacturer
Article number
Rated DC current [A] (DC)
210
-
-
-
Rated armature supply
voltage [V]
400
480
575
- - -
Contactor armature circuit
-
Main contactor AC1, 275 A
Siemens
3RT1456-6AP36
Contactor field circuit
-
Field contactor designed for AC1
Siemens
3RT2015-2AP01
6RA8078_XXXXX_0AA0
Value
Designation
Manufacturer
Article number
Rated DC current [A] (DC)
280
-
-
-
Rated armature supply
voltage [V]
400
480
- - -
Contactor armature circuit
-
Main contactor AC1, 275 A
Siemens
3RT1456-6AP36
Contactor field circuit
-
Field contactor designed for AC1
Siemens
3RT2015-2AP01
6RA8081_XXXXX_0AA0
Value
Designation
Manufacturer
Article number
Rated DC current [A] (DC)
400
-
-
-
Rated armature supply
voltage [V]
400
575
- - -
Contactor armature circuit
-
Main contactor AC1, 400 A
Siemens
3RT1466-6AP36
Contactor field circuit - Field contactor designed for AC1
Field contactor designed for AC1
Siemens
Siemens
3RT2023-2AL20
3RT2023-2AL24
6RA8082_XXXXX_0AA0
Value
Designation
Manufacturer
Article number
Rated DC current [A] (DC)
450
-
-
-
Rated armature supply
voltage [V]
480 - - -
Contactor armature circuit - Main contactor AC1, 400 A Siemens 3RT1466-6AP36
Contactor field circuit - Field contactor designed for AC1
Field contactor designed for AC1
Siemens
Siemens
3RT2023-2AL20
3RT2023-2AL24
6RA8085_XXXXX_0AA0
Value
Designation
Manufacturer
Article number
Rated DC current [A] (DC)
600
-
-
-
Rated armature supply
voltage [V]
400
480
575
- - -
Contactor armature circuit
-
Main contactor AC1, 690 A
Siemens
3RT1476-6AP36
Contactor field circuit - Field contactor designed for AC1
Field contactor designed for AC1
Siemens
Siemens
3RT2023-2AL20
3RT2023-2AL24
