Glossary
Ethernet station
Participants in the Ethernet sub-net without local connection for the PC.
PMI
The arrangement of operating and display elements on a fire control panel or on a fire terminal. Includes the
LEDs, buttons, the display, and the operation options such as the key switch, fire brigade control and
display (FBA), and the EVAC NL Person Machine Interface.
Router station
Participant in the SAFEDLINK sub-net for the connection between the SAFEDLINK sub-net and the
Ethernet sub-net (FCnet/C-WEB/LAN) via the Ethernet switch (modular) FN2012-A1.
Site
Depiction of fire detection installation: The top level in the figure showing the installed system. Combines
hardware tree, detection tree, and control tree.
Standby router station
Participant in the SAFEDLINK sub-net, in redundancy to the router station, for the connection between the
SAFEDLINK sub-net and the Ethernet sub-net (FCnet/C-WEB/LAN) via Ethernet switch (modular) FN2012-
A1.
Station
Unit for system control. Fire control panel or fire terminal.
