Accessories
7.1 Reactor and filter
Power Module PM240
100 Hardware Installation Manual, 07/2009, A5E00807525B AD
Table 7- 20 Technical specifications of the sine-wave filters (table 5 of 5)
Suitable for Power Module with rated power (HO) of
132 kW 160 kW 200 kW
Feature
FSGX
MLFB of the sine-wave
filter
6SL3000-2CE32-8AA0 6SL3000-2CE33-3AA0 6SL3000-2CE34-1AA0
MLFB of the suitable Power
Module
6SL3224-0XE41-6UA0 6SL3224-0XE42-0UA0 6SL3224-0XE41-3UA0
dv/dt limiting ≤ 500 V/µs
Power loss at 50 Hz 230 W 180 W 230 W
Motor connection Flat connector for M10 cable lug
Connection to Power
Module
Flat connector for M10 cable lug
Degree of protection IP00
Overall dimensions
Width
Height
Depth
620 mm
320 mm
300 mm
620 mm
370 mm
360 mm
620 mm
370 mm
360 mm
Installation clearance
Top
Bottom
Side
100 mm
--
100 mm
Fixing dimensions
Width
Depth
225 mm and 150 mm
280 mm
225 mm and 150 mm
320 mm
Fixing screw 6 × M10
Weight 127 kg 136 kg 198 kg
Possible as base
component
no
