Accessories
7.1 Reactor and filter
Power Module PM240
Hardware Installation Manual, 07/2009, A5E00807525B AD
99
Suitable for Power Module with rated power (HO) of
15 kW … 18.5 kW 22 kW 30 kW … 37 kW
Feature
FSD FSE
Weight 24 kg 34 kg 45 kg
Possible as base
component
no
Table 7- 19 Technical specifications of the sine-wave filters (table 4 of 5)
Suitable for Power Module with rated power (HO) of
45 kW … 55 kW 75 kW 90 kW … 110 kW
Feature
FSF
MLFB of the sine-wave
filter
6SL3202-0AE31-5SA0 6SL3202-0AE31-8SA0 6SL3000-2CE32-3AA0
MLFB of the suitable Power
Module
6SL3224-0BE34-5 . A0 6SL3224-0BE35-5 . A0 6SL3224-0BE38-8UA0
6SL3224-0BE41-1UA0
dv/dt limiting ≤ 500 V/µs
Power loss at 50 Hz 180 W 190 W 200 W
Motor connection Screw terminals 50 … 150 mm² Flat connector for M10 cable
lug
Connection to Power
Module
Screw terminals 50 … 150 mm² Flat connector for M10 cable
lug
Degree of protection IP00 without terminal cover, IP20 with terminal cover IP00
Overall dimensions
Width
Height
Depth
350 mm
440 mm
305 mm
350 mm
468 mm
305 mm
620 mm
320 mm
300 mm
Installation clearance
Top
Bottom
Side
100 mm
-
100 mm
Fixing dimensions
Width
Depth
320 mm
255 mm
320 mm
155 mm
225 mm and 150 mm
280 mm
Fixing screw 4 × M8 6 × M10
Weight 63 kg 80 kg 124 kg
Possible as base
component
no
