Accessories
7.1 Reactor and filter
Power Module PM240
Hardware Installation Manual, 07/2009, A5E00807525B AD
87
Table 7- 8 Technical specifications of the line filters class A
Suitable for Power Module with rated power (HO) of
0.37 kW ... 1.5 kW 90 kW ... 110 kW 132 kW ... 200 kW
Feature
FSA FSF FSGX
MLFB of the line filter 6SE6400-2FA00-6AD0 6SL3203-0BE32-5AA0 6SL3000-0BE36-0AA0
MLFB of the suitable Power
Module
6SL3224-0BE13-7UA0
6SL3224-0BE15-5UA0
6SL3224-0BE17-5UA0
6SL3224-0BE21-1UA0
6SL3224-0BE21-5UA0
6SL3224-0BE38-8UA0
6SL3224-0BE41-1UA0
6SL3224-0XE41-3UA0
6SL3224-0XE41-6UA0
6SL3224-0XE42-0UA0
Power loss at 50 Hz 0.5 ... 1.5 W 60 W 55 W
Line connection Screw terminals 2.5 mm² On housing via M8 screw
stud
M10 connecting lugs
Connection to Power
Module
Cable, 400 mm length On housing via M8 screw
stud
M10 connecting lugs
Degree of protection IP20 IP00
Overall dimensions
Width
Height
Depth
73 mm
200 mm
42.5 mm
240 mm
360 mm
116 mm
400 mm
265 mm
140 mm
Fixing dimensions
Width
Height
56 mm
187 mm
210 mm
220 mm
240 mm
250 mm
Fixing screw 4 × M4 4 × M8 4 × M10
Weight 0.6 kg 12.4 kg 19 kg
Possible as base
component
yes no
Table 7- 9 Technical specifications of the line filters class B
Suitable for Power Module with rated power (HO) of
0.37 kW ... 1.5 kW 2.2 kW ... 4 kW 5.5 kW ... 11 kW
Feature
FSA FSB FSC
MLFB of the line filter 6SE6400-2FB00-6AD0 6SL3203-0BE21-6SA0 6SL3203-0BD23-8SA0
MLFB of the suitable Power
Module
6SL3224-0BE13-7UA0
6SL3224-0BE15-5UA0
6SL3224-0BE17-5UA0
6SL3224-0BE21-1UA0
6SL3224-0BE21-5UA0
6SL3224-0BE22-2AA0
6SL3224-0BE23-0AA0
6SL3224-0BE24-0AA0
6SL3224-0BE25-5AA0
6SL3224-0BE27-5AA0
6SL3224-0BE31-1AA0
Power loss at 50 Hz 0.5 W ... 1.5 W 2.0 W ... 4.0 W 7.5 W ... 15 W
Line connection Screw terminals 2.5 mm² Screw terminals 2.5 mm² Screw terminals 4 mm²
Connection to Power
Module
Cable, 400 mm length Cable, 400 mm length Cable, 400 mm length
Degree of protection IP20
