Connector designation: X53 / X54
Connector type: 4-pin plug connector
Max. cable length: 0.6 m
Table 1-20 Assignment of connector X53
Pin Name Type Meaning
1 KT-OUT1
O
Output 1 lamp
2 KT-OUT2 Output 2 lamp
3 KT-OUT3 Output 3 lamp
4 M V Ground
Table 1-21 Assignment of connector X54
Pin Name Type Meaning
1 KT-OUT4
O
Output 4 lamp
2 KT-OUT5 Output 5 lamp
3 KT-OUT6 Output 6 lamp
4 M V Ground
Interfaces for two handwheels X60 / X 61
Interface: Handwheel 1 Handwheel 2
Connector designation: X60 X61
Connector type: 15-pin Sub-D socket
Max. cable length: 25 m
Table 1-22 Assignment of connectors X60/X61
Pin Name Type Meaning
1 P5HW V 5 V power supply
2 M V Ground
3 HW1_A / HW2_A I Handwheel pulses track A
4 HW1_XA / HW2_XA I Handwheel pulses track A (negated)
5 N.C. - Not connected
6 HW1_B / HW2_B I Handwheel pulses track B
7 HW1_XB / HW2_XB I Handwheel pulses track B (negated)
8 N.C. - Not connected
9 P5HW V 5 V power supply
10 N.C. - Not connected
11 M V Ground
General information and networking
1.3 Connecting
Operator panel front: OP 012
Manual, 09/2016, A5E36371591B 33
